Thermal mass in an incubator

Visualizing things is always dramatically cooler than just “knowing” them, and the conditions within an incubator are no exception. Graphing the temperature and humidity over time turned out really cool to see. This is about the only real life example I’ve personally ever come across that looks like a math class. Specifically, both the humidity and the temperature are pretty damn consistently periodic, and they’re pretty close to sinusoidal. Because relative humidity depends on temperature, the graph of relative humidity is very obviously the composition of two functions with different frequencies (the “absolute” humidity and the temperature).

This is mostly a function of a really naive heating and humidifying implementations: heat until a threshold, turn heater off, passively cool until a threshold, turn the heater on, repeat. Same for the humidifier.

humidity

That’s all I wanted to show about the humidity, just that it looks like math class.

temperature
Detail view of the temperature over time (roughly 9 hours represented)

Taking some liberties with the specific values, the heat can roughly be graphed by:

original-function
initial stab at heat

Breaking it down, this means it’s averaging about 38.2°C, varies by ±1.45°C, and has a heat/cool cycle every 5.6 seconds. In terms of an incubator, that’s too hot compared to the target temperature, varies by more than is ideal, and… has a heat/cool cycle every 5.6 seconds. I don’t really know if there are pros/cons to longer or shorter heating cycles, I imagine some middle ground is likely ideal so 5.6s doesn’t seem unreasonable.

In particular, I’m way overshooting the upper heat threshold as the heater remains hotter than ambient for a bunch of seconds. Rather than solve this the “right” way, e.g. with PID algorithm, I continued to mess around. Aside from changing the heating/cooling thresholds, one of the more interesting things to do is add some thermal mass. I had some preconceived notions that thermal mass was like a battery but for heat.

after-adding-water-bucket-detail
Detail view of the temperature over time after adding a jug of water (roughly 9 hours represented)

May be a bit hard to see close up, but it’s quite a bit more clear when zoomed out (ignoring the outliers from me mucking with things). No water jug is on the left, water jug is on the right.

after-adding-water-bucket
The blue line in the center is where I added the bucket of water

With some more liberties taken with the numbers, the graph of the temperature after adding a jug of water is roughly:

second-function

In practical terms:

  • now averaging 37.8°C (previously 38.2°C)
    • I’m guessing that the thermal mass is “resisting” heating caused by overshooting the threshold, dropping the max temperature reached in the heating cycle
  • now varying ±1.05°C (previously 1.45°C)
    • this is a great improvement! The incubator spends more time closer to the target temperature
  • now has a period of 6.7s (previously 5.6)
    • the heating/cooling cycle takes a full extra second now that it’s heating/cooling the water.
    • I’m not sure if this is better or worse, seems better that it’s more gradual I guess?

Takeaways

  • if you have time series data, graph it! It’s almost always rewarding to see
  • all else held equal, a little bit of thermal mass has a dramatic impact
  • thermal mass is barely a “battery for heat”

After seeing the impact of the thermal mass, I went back and revisited the concept of “like a battery, but for heat”. While that’s kind of true, it’s pretty misleading. A battery is a battery because it stores a significant amount of energy in a usable form. In terms of the amount of heat stored in thermal mass (how much energy it takes to heat water from the low temperature threshold to the high temperature threshold), one could ask “how long would it stay within acceptable temperature if the power went out” or similar, and the answer is: barely any time at all, on the order of seconds.

By my current understanding, “thermal mass” isn’t really about being a thermal battery so much as it’s about resisting temperature change. Relative to a battery, a jug of warm water has low energy density. Relative to the same amount of air though, it’s incredibly high energy density, and that’s the key.

Signal is a bit of a disappointment

Recently I was looking to try and use Signal on my PinePhone, and the more I got into it the more my love of Signal diminished.

One of my biggest uses for my cellphone is Signal Messenger. It’s been eye opening (in a disappointing way) trying to get it on my PinePhone. I’ve started thinking that a messaging app is like the “hello world” of deployment – send information cross-platform, sync it, handle failures etc. Whether that message is literally user text or driving an application seems less important. The baseline deployment aspects seem pretty similar. Anyways, a few disappointing things about Signal:

Signal will not federate (actively come out against it)

This one is I think the biggest disappointment. It feels a bit like you’re damned if you do, damned if you don’t, but a non-federated messaging platform doesn’t feel like “the future”. It’s depressing to think 20 years from now we’re still going to struggling with the same fragmentation and mega-corp “lure-and-lock” style of closed ecosystem shenanigans (Blackberry was bad for that, Apple is perhaps the most egregious in modern times). The number of high profile chat applications built off the Signal technology that cannot interact with one another is already sad.

It’s worth reading the blog post about it, as it’s definitely a tough decision to make: Reflections: The ecosystem is moving

That said, there are various projects that provide unofficial clients for Signal. As these are using the official Signal servers, I’m curious what the organization thinks of them – maybe custom clients can fill most of the gaps?

There appears to be no intention for a web client, due to security concerns

There are some good reasons for this, so it’s a bit of “reality is disappointing”

The fundamental problem with web interfaces is: there’s no way to version, sign and securely distribute a web page. Instead, you’re re-requesting the code you’ll run every single time you visit the site (making audits practically impossible).

This effectively reduces the security of your end-to-end encrypted communication to that of your SSL connection to the server, i.e. you’re only as secure as the CA system. Anyone able to intercept the client-server SSL connection (and the server itself) can silently change the code you receive and execute, with a very low risk of getting caught. This is why products which offer end-to-end encrypted communication through in-browser crypto are often considered snake oil, unless they use some form of a packaged & signed browser extension.

https://community.signalusers.org/t/google-to-retire-chrome-apps-what-will-be-with-signal-desktop/469/6

Limited device access

First of all, everything is linked to a mobile number, so there’s no desktop only client. The desktop client is linked to a cell phone that has a phone number associated with it. Increasingly, I don’t think I have any reason to have a cell number – it’s mostly an avenue for spam/scams to reach me at this point. Due to the terrible quality of cell reception around me, I make most of my calls via data (Signal calls and Hangouts Dialer). This implies there’s effectively a subscription price for Signal if you don’t have/don’t want a cell phone – pay your local telecom for a number, or lose access. If anyone knows how to get a free/extremely cheap cell phone number in Canada I’m all ears.

Adding on to that, each account has a max limit of 1 mobile device and 5 non-mobile devices. In a very real situation I’ve been in, where I have one phone with my SIM in it and another one on Wi-Fi, they can’t both use Signal. This feels like a really arbitrary and silly restriction that is a pain in the ass to work around. I’m really curious if there’s a technical reason for this – e.g. why not make it 6 cumulative devices?

What are the alternatives?

Presently, I think the most compelling “alternative” to Signal is Matrix. Alternative is in quotes because it’s dramatically different in a number of ways. The reason I think it’s viable is the number of high quality bridges that exist and work today. This breaks down the walls a bit when it comes to moving to Matrix without leaving contacts behind.

Noting that I’m extremely biased by working in IT, but Matrix feels like it could be a modern libpurple. I’ll be making a sincere effort to give Matrix a shot and see how it goes. That said, a worrying possibility is that Matrix steals libpurple users and doesn’t significantly grow the ecosystem of people interested in messengers that are compatible with one another. I guess we’ll see…

Incubator break: 3D printed detour

This stage is where everything went sideways. I was not making significant progress on the incubator for 2 very distinct reasons:

  • On the electrical front, I continued to not know anything and was losing motivation. I couldn’t figure out the right direction to go, I was spending money on components, waiting ~6 weeks for them to arrive, then figuring out I had made some mistake or misunderstood what I wanted or not realized there was a better way.
  • On the mechanical front, making stuff is HARD. Designing mechanisms really does take time and experience. Making things with wood is imprecise unless you have a lot of knowledge and skill, which extends to both how to work with wood and the wood itself. Making things with metal is expensive, daunting and messy. 3D printing is pretty much the holy grail for things like this – clean, cheap, easy, and sharable.

That brought me to a point where I finally decided to buy a “real” 3D printer.

3D printer!

I had been interested in 3D printing for ages. I had been peripherally following it since it became “mainstream” with the RepRap project (I started paying attention ~2007). It was always a bit out of reach because I had none of the skills or money to dive into it. On the other hand, it always felt like in some alternate universe I would have been right in the midst of it. Regardless, I had wanted a 3D printer for ages. I had personal experience with one in the past, but it wasn’t a good experience.

The M3D Micro came along ~2014, and it was SO cheap that it seemed like a good opportunity to figure out if I wanted to save up and buy a nice one or abandon the whole idea. My wife and I bought one, and while it was interesting it was also a complete piece of garbage. Now that I know more about 3D printing, I wouldn’t even give it to someone for free – there are virtually no quality components in the whole thing. It put me off so much that I didn’t look at 3D printing again until I was staring down the barrel of this incubator project.

Do not buy this. If you see one on the ground, consider not even stopping to pick it up.

With an actual use case (mounting things, building cases/enclosures, gears, connectors), I was ready to reconsider 3D printers. The “go-to” printer at the time was the Prusa MK3. It was a little expensive, but had thousands of great reviews. I went for it, and proceeded to spend ~a year getting completely distracted by 3D printing.

The progression of 3D printing I found was:

  1. print out all sorts of random desk baubles and tchotchkes (low poly Pokemon , succulent pots, etc) while you’re getting an understanding of printing.
    • this helps build out the very practical “how does something go from a file to an object” as well as what polymers exist for printing, what their trade-offs are, how things can fail etc.
  2. print out some useful things
    • all the sudden you find out you can print a hinge, or a clip or a vice or something does something. For me, the big eye opener was cases for Raspberry Pi models and custom gears
  3. design something custom
    • the printing itself is no longer the barrier, it’s CAD skills. The world opens up as you can now attach anything to anything with a custom, perfect fit mount. You can build gear boxes with a coupler that fits whatever random cheap motor you’re able to find, powered by a PSU that’s safely enclosed within a custom printed case and mounted robustly without having to drill or tap or cut.

With that said, I picked up a Prusa MK3:

https://makezine.com/wp-content/uploads/2017/09/Prusa_i3_mk3_White-1.jpg
Buy this!

It’s roughly the #1 most enjoyable thing I’ve ever spent money on. Upon spending ~1100$ CAD (after shipping/taxes/exchange rate), the only thing I regretted was not buying it sooner.

Inky wHAT with Raspberry Pi 4

If you have a Raspberry Pi 4 and an Inky wHAT ePaper/eInk/EPD, you’ll likely want to use one with the other at some point. Here’s everything I did from opening the box of the Raspberry Pi and Inky wHAT to running the example code:

  • Assemble the required ingredients:
    • Raspberry Pi 4
    • MicroSD card + SD card adapter + SD card reader (laptop maybe?)
    • USB-C cable and 5V power supply
  • Download a SD card flashing tool, e.g. from https://www.raspberrypi.org/downloads/
  • Run the flashing tool, and flash an OS, I used Raspberry Pi OS Lite (Raspbian?)
  • Before ejecting the SD card, set up your Wi-Fi connection and SSH
  • For SSH:
    • Create an empty file named “ssh” (no extension) in the SD card’s boot partition
  • For Wi-Fi:
    • Create a file “wpa_supplicant.conf” in the SD card’s boot partition with your configuration
ctrl_interface=DIR=/var/run/wpa_supplicant GROUP=netdev
update_config=1
country=<Insert 2 letter ISO 3166-1 country code here, e.g. CA for Canada>

network={
    ssid="<Name of your wireless LAN>"
    psk="<Password for your wireless LAN>"
}
  • Eject the SD card from your computer
  • Put the SD card in the Pi
  • Connect the Pi to power
  • Wait a minute or two
  • Determine the IP address of the Pi as it joins your Wi-Fi
  • ssh into your Pi
    • e.g. ssh pi@192.168.1.215 with password ‘raspberry
  • Generally I update the PI first thing, just so I know where I stand
    • sudo apt update
    • sudo apt upgrade -y
    • sudo apt autoremove
    • sudo reboot
  • Now, enable SPI and also I²C (I’m not sure why it needs both)
Select ‘Interfacing Options’
Select ‘SPI’
Enable it! Repeat for I2C
  • Now on to the Pimoroni aspect!
  • They recommend the ol’ magic script, which is a great way to start:
  • Now, the moment of truth, run one of the included examples
    • change directory into ~/Pimoroni/inky/examples
    • sudo python name-badge.py --type "what" --colour "red" --name "Inigo Montoya"
    • Note that “sudo” is required because you’re accessing the GPIOs
    • Also note the British spelling of “colour” – at this time “color” does not work

It looks absolutely fantastic in person. I love eInk displays, so I’m jacked up about this. Now time to create my own images!

Incubator build: Part 3 – build something

With the particularly sketchy parts of both the hardware and software “figured out”, I was now ready to actually build something that might some day hold eggs. Mostly this consisted of leaning together some spare materials I found, with just enough tape and fasteners to keep it from falling over. The BOM for this is:

  • an old single pane window
  • a 2×10 cut into 6 pieces such that it makes a rectangle (4 sides) and a bottom (2 pieces)
  • a piece of scrap vapor barrier
  • a NodeMCU ESP32 dev board
  • a 12V computer fan
  • a breadboard
  • two DHT22 sensors
  • a lightbulb (with fixture)
  • a loaf pan (for water)
  • an unused computer power supply (never to be used again after this…)
  • a smattering of Wago connectors and wires
  • a transistor
  • a bunch of screws and some tape
  • some literal garbage, to “mount” things (an empty cardboard box for some staples or something, and a broken off piece of wood?)
  • an extension cord with the female end cut off

I wish I had taken more pictures, because I was super proud at the time, but this is the only one I could find.

20180408_205442
It’s not pretty, but it sure is a box!

As you can see, this is an electrical hazard, it’s filthy, and barely held together. It was also among the coolest things I’d ever built at that point. It seemed to work half decently – as long as the water was kept topped up, the humidity seemed pretty stable. With no real thermal mass except for the air and the small amount of water, the temperature fluctuated quite a bit. By virtue of the temperature fluctuating, the relative humidity also fluctuated significantly. Either way, it was a bit hard to tell exactly how it was performing because I was just dumping the readings out into the terminal and publishing them as MQTT messages (nothing was subscribed).

Automatic egg turner

At the same time as I reached the limits of my very basic understanding of electrical components, I was struggling to come up with a way to make an egg turner. I knew I wanted to automatic egg turner to be a part of this build, but I couldn’t figure it out. There are a bunch of recommendations on the internet (e.g. use the old style car antenna motor), but they were not particularly accessible (in terms of availability or price point). Sure, it’s a great tip to use an old antenna motor from the scrap heap, but it’s not that great a tip if you don’t have old antenna motors sitting around. Intentionally ordering something that’s only recommended because it’s cheap/accessible would be like buying used pallets to make woodworking product. It just misses the point.

Embarrassingly, this is about as close as I got. The idea was to mount a little wooden sled on the drawer pull, and have that push back and forth. It “worked” with some very generous interpretations of the word…

20180505_140918
It’s not pretty, but it… also doesn’t really work that well

Assembling robust mechanisms that do even simple things is also hard! This is well outside my domain, so I don’t even know where you go on the Internet to look up “DIY convert rotational movement into oscillating linear movement”. Ironically, searching that exact phrase leads to some pretty great resources. At the time I didn’t realize that’s what I wanted though. Even if you DO find something, you have to build it in a way that doesn’t suck.

And this is where the whole project truly became hideously sidetracked…

Digi-Key/Mouser vs. Adafruit/SparkFun

While trying to build an incubator, I very quickly ran into the limits of my very basic electrical component understanding. As I tried to tackle new problems, I continually had to do new things. Specifically, one of the issues I had was DHT22 sensors locking up. The easiest/best thing I could think of was to use a transistor to toggle the power supplied to the sensors, so my micro controller could reboot them when necessary.

Getting that transistor set up was the most complicated electronics thing I had done to date. When you don’t understand the theory, everything is hard. It’s easy to forget once you know everything, but electronic components are bruuuuutally complicated when you don’t know anything. As soon as anyone mentions PNP vs NPN, you’re off the deep end.

I wanted a switch I could control with a GPIO, I didn’t want a crash course in electrical theory. When you know, you can quickly make a wide variety of components work (or at least rule them out). When you don’t know, you can’t even figure out what area of component you should be looking up to buy. Add in the lead time for getting those new components, only to find out when you go to use them that they’re not compatible with something else you ordered a month ago, and it’s a rough go. I think there’s something missing between the SparkFun/Adafruits of the world and the Mouser and Digi-Keys of the world. One end of the spectrum is basically premium kit builds with a curated component selection, the other end is a ridiculously overwhelming parts list of ultra specific items.

As an example, here’s an example of the search results for “transistor” on Mouser (it actually leads to the “All Products | Semiconductors | Discrete Semiconductors | Transistors” section):

Capture
are these even words?!

And here’s most of the first page of results for “transistor” on Adafruit:

Capture
yes, the first 8 results were for t-shirts

So, do I start poking through the 40 000 things that are “transistors” and try and figure out what I actually want? It’ll take me multiple evenings to have a basic knowledge of the dozen words used to categorize them. Or do I start trying to find an Adafruit project that happens to line up with what I’m doing and therefore suggests a specific part? Neither is particularly enticing.

To be clear: I love all these sites. If you want a specific thing, Mouser/Digi-Key are absolutely invaluable. If you want to get jacked up about technology as hobby and get project ideas, Adafruit and SparkFun are fantastic resources. Adafruit and SparkFun also produce a ton of amazing “tutorial” style content as well. If you’re somewhere in the middle though and you don’t already have the knowledge, you’re a bit boned. I had a theoretical idea what I wanted, but it wasn’t an existing project, so now what?!

Maybe there’s an opportunity for something in the middle – a “choose your own adventure” style catalog that asks some rudimentary questions and guides you to an appropriate selection of components. Or maybe the answer is to just learn enough to be able to make the decision myself…
